220V/230V Antifreeze Pipe Heating System Self-Regulating Heat Trace Cable Made of Silicone Rubber


Kategori:

Beskrivning

Produktbeskrivning
Self regulating cables have an adaptable heat output and consist of two parallel bus wires embedded in a networked plastic heat element with surrounding carbon particles. If the temperature increases during operation, the plastic will expand and the distance between the carbon particles increases, resistance increases and output drops. When ambient temperature falls, this process is reversed and heat output increases – this is the principle of self regulation.
Self regulating cables intelligently adjust heat output according to ambient or air temperature – whenever the heat loss of the insulated pipe, tank or heated process increases (as ambient temperature drops), the heat output of the cable increases. Omvänt, when the heat loss decreases (as the ambient temperature rises or product flows), the heating cable reacts by reducingits heat output.
Specifikation
Typ
Kraft(W/M 10℃)
Max maintain temp(℃)
Max.exposure temp(℃)
Min. installation temp(℃)
Max. length of single power supply
Low temperature series
10,15,25,35
65℃±5℃
105℃
-60℃
7*0.5 100meters;19*0.32 120meters.
Medium temperature series
35,45,50,60
105 ℃ ± 5 ℃
135℃
-40℃
7*0.5 100meters;19*0.32 120meters
High temperature series
35,50,60
135 ℃ ± 5 ℃
155℃
-30℃
7*0.5 100meters;19*0.32 120meters
Detaljer Bilder
Förpackning & Leverans
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
företagsprofil
we have passed the industry qualification certification to protect the product quality. We provide one-stop procurement services to reduce the procurement cost for customers.We offer a service of batch remittance to alleviate the pressure on customerscapital turnover.
FAQ
1. vilka är vi?Vi är baserade i Jiangsu, Kina, start from 2021,sell to North America(90.00%),Domestic Market(10.00%). Det finns totalt ca 11-50 personer på vårt kontor.2. hur kan vi garantera kvalitet?Alltid ett förproduktionsprov innan massproduktion;Alltid slutbesiktning före leverans;3.vad kan du köpa av oss?Värmeelement, Ventilation Products, Thermocouple4. varför ska du köpa från oss inte från andra leverantörer?we have passed the industry qualification certification to protect the product quality. We provide one-stop procurement services to reduce the procurement cost for customers.5. vilka tjänster kan vi tillhandahålla?Godkända leveransvillkor: FOB,EXW,DDP;Godkänd betalningsvaluta:USD;Godkänd betalningstyp: T/T,L/C,D/P D/A;Språk som talas:engelsk,kinesiska,franska
