25mmx19mm Rtd Sensors PT100 Self-Adhesive Polyimide Fast Response Surface Mount Stick on RTD Sensor 260C 3 Проволока 4 Проволока
25mmx19mm Rtd Sensors PT100 Self-Adhesive Polyimide Fast Response Surface Mount Stick on RTD Sensor 260C 3 Проволока 4 Проволока
Описание
25mmx19mm Rtd Sensors PT100 Self-Adhesive Polyimide Fast Response Surface Mount Stick on RTD Sensor 260C 3 Проволока 4 Проволока
Описание продукта
The surface-mount RTD temperature sensor mounts on flat or curved surfaces and provides Class A accuracy for critical temperature monitoring applications. Based on a 2 x 2 x 0.8 mm thin-film platinum RTD and supplied with bare 3-wire leads as a standard configuration (connector optional), it can be customized for use in a wide variety of applications. The sensor can be easily applied with its self adhesive backing, Use the Sensor to monitor chip, heat sink, and environmental temperatures in electronic devices; check piping or ducting temperatures;monitor motor and transformer core heat; test insulation capabilities; and check other applications in which surface and/or gradient temperatures need to be monitored or controlled.
Размер:25mm*19mm
Материал:Polyimide
Element: Pt100(A class, B class, 1/3B class)
wire :1.4м(customized size)+ 3wire
Спецификация
наименование товара | Stainless steel PT100 RTD Temperature Sensor |
Модель | ПТ100 (K/E/J/T/CU50 optional） |
Defalut Size | 25*19мм |
Точность | Class B / Class A/ Class 2B, PT1000 Class 1/3 Б |
Probe Length | 50мм, 100мм, 150мм, 200мм, 250мм, 300мм, 400мм, 500mm optional |
Wire Material | 3 Wire Teflon shield silver plated copper wire （Waterproof Silicone rubber/glass fiber optional） |
Wire Length | 0.5M/1M/2M/3M optional |
Temp range | PT100 -50℃-200℃CU50 -50℃-150℃K 0℃—600℃E 0℃—400℃ |
Terminals | U type Terminals , mini connectors |
Product Advantage:1)High Precision Temperature control probe2)Accurate measurement accuracy, high sensitivity, wide measurement range 0-500℃3)Accurate measurement (imported chip)4)быстрый ответ,anti-interference5)Good temperature resistance
Different end user are avaliable
Other mode are avaliable, feel free to contact us
Упаковка & Доставка
Чтобы лучше обеспечить безопасность ваших товаров, профессиональный, экологически чистый, будут предоставлены удобные и эффективные услуги по упаковке.
