KS/KB/KW Cast Steel Water Thermocouple Temperature Measuring Probe One-Time Rapid Thermal Rod for Metallurgy Paper Instrument

KS/KB/KW Cast Steel Water Thermocouple Temperature Measuring Probe One-Time Rapid Thermal Rod for Metallurgy Paper Instrument

Categoria:

Descrição

KS/KB/KW Cast Steel Water Thermocouple Temperature Measuring Probe One-Time Rapid Thermal Rod for Metallurgy Paper Instrument
Descrição do produto

Product Features】 The steel liquid sampler is divided into single chamber and double chamber structures, which have the characteristics ofconvenient use. The sampler is used on site to quickly save time and ensure the quality of steel, in order to reduce waste and improve economic efficiency. Production sampler: used for sampling molten steel that does not require deoxygenation in refining and large ladle after furnace, intermediate ladle; Used for sampling molten steel that needs deoxidation in converters, electric furnaces, open hearth furnaces, etc.. The success rate of sampling is above 98%, the steel sample is full, dense and glossy, and there are no pores. The sampler style can be made according to user requirements. The main features and scope of application are used for rapid extraction of formed steel samples for spectral analysis. It has the characteristics of simple structure and convenient application

【 Instructions for use】
1.Insert the sampler into the dedicated measuring gun;
2.During the measurement,the molten steel sampler is tilted at 60-65 ° and inserted into the molten steel at a depth of over 350MM, with a sampling time of 4-6 seconds; 3.After taking out the sampler from the metal furnace or ladle, gently tap it on the ground, and the steel sample will fall to the ground.【Matters needing attention】1. Samplers must be protected from dampness during storage. 2. Molten steel must be sampled at temperatures above 1400 C. 3. Avoid strong vibration to prevent quartz tube from breaking. 4. Aluminum sampler is used as deoxidizer for steel sample with high oxygen content. Aluminum-free sampler is used asdeoxidizer-free sampler for steel sample with low oxygen content.
Cast Steel Water Thermocouple
Cast Steel Water Thermocouple
Especificação
Nome
Tipo
specifications
Outer diameter/ thickness of steel sample （mm）
Diameter/length of injection port(milímetros)
Molten steel sampler
KQNO01G(KQN-01H)
No deoxidizer
Φ34*12
Φ7*(20-45)
Molten steel sampler
KQN-002G
No deoxidizer
Φ34*14
Φ7*(20-30)
Molten steel sampler
KQN-003G(KQN-031)
No deoxidizer
Φ34*17
Φ6*(20-30)
Molten steel sampler
KQN-004G（KQN-04
No deoxidizer
Φ（32-36）*（65-75）
Molten steel sampler
KQY-10IG
Deoxidizer (for low oxygen)
Φ34*12
Φ7*(20-45)
Molten steel sampler
KQY-201G
Deoxidizer (high oxygen)
Φ34*12
Φ7*(20-45)
Molten steel sampler
KQN-00IT
No deoxidizer
Φ34*12
Φ10*15
Molten steel sampler
KQN-002T
No deoxidizer（rod）
Φ6*50
Certificações
Cast Steel Water Thermocouple
Cast Steel Water Thermocouple
Embalagem & Entrega
Cast Steel Water Thermocouple
Cast Steel Water Thermocouple
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Perguntas frequentes
1. quem somos nós?Estamos baseados em Jiangsu, China, start from 2021,sell to North America(90.00%),Domestic Market(10.00%). Há um total de cerca de 11-50 pessoas em nosso escritório.2. como podemos garantir qualidade?Sempre uma amostra de pré-produção antes da produção em massa;Sempre inspeção final antes do envio;3.o que você pode comprar de nós?Elemento de aquecimento, Ventilation Products, Thermocouple4. por que você deveria comprar de nós e não de outros fornecedores?we have passed the industry qualification certification to protect the product quality. We provide one-stop procurement services to reduce the procurement cost for customers.5. quais serviços podemos fornecer?Termos de entrega aceitos: FOB,EXW,DDP；Moeda de pagamento aceita:USD;Tipo de pagamento aceito: T/T,L/C,D/P D/A;Língua falada:Inglês,chinês,Francês
