Infrared Heating Part 12K Carbon Fiber Electric Warm Floor Part Customizable Heating Capacity 500V/300V Voltage
설명
제품 설명
Carbon fiber heating wire is an electric heating element with carbon fiber as the heating body, featuring high efficiency, energy saving, safety and reliability. Here is the detailed product information:
Structure and Materials:
The core heating material is carbon fiber yarn, which is transformed from organic fibers through heat treatment and has an extremely high carbon content. The external insulation layer and sheath materials are diverse, including Teflon, glass fiber, 실리콘, PVC, 등., and can be selected according to different usage scenarios and requirements.
Technical Specifications
Rated Voltage: The rated voltage varies for different products. Common ones include 600V, and there are also those suitable for low-voltage scenarios such as DC 36V or AC 250V, 등.
온도 범위: The general operating temperature range is from -60℃ to +200℃, allowing for use in a wide temperature environment.
Resistance Range: The resistance value varies depending on the carbon fiber specification. 예를 들어, the resistance of 1K carbon fiber heating wire can reach 133Ω/m, while the resistance of 24K is approximately 17Ω/m.
Insulation Performance: The insulation performance is excellent. For instance, the power frequency withstand voltage of TQF carbon fiber PTFE heating wire can reach 3500V, and the insulation strength of the outer sheath is ≥4000V.
Rated Voltage: The rated voltage varies for different products. Common ones include 600V, and there are also those suitable for low-voltage scenarios such as DC 36V or AC 250V, 등.
온도 범위: The general operating temperature range is from -60℃ to +200℃, allowing for use in a wide temperature environment.
Resistance Range: The resistance value varies depending on the carbon fiber specification. 예를 들어, the resistance of 1K carbon fiber heating wire can reach 133Ω/m, while the resistance of 24K is approximately 17Ω/m.
Insulation Performance: The insulation performance is excellent. For instance, the power frequency withstand voltage of TQF carbon fiber PTFE heating wire can reach 3500V, and the insulation strength of the outer sheath is ≥4000V.
사양
사양:상품명: Silicone Rubber Carbon Fiber Heating CableInsulating materials: Silicone RubberTemperature: 250-300 Degrees Celsius Limit (We have temperature controller）Heating Conductor: 1K=1000pcs Carbon Fiber Heating Wires=410Ω/Meter Outside diameter=2mm2K=2000pcs Carbon Fiber Heating Wires=220Ω/Meter Outside diameter=2mm3K=3000pcs Carbon Fiber Heating Wires=133Ω/Meter Outside diameter=2mm6K=6000pcs Carbon Fiber Heating Wires=66Ω/Meter Outside diameter=2mm9K=9000pcs Carbon Fiber Heating Wires=55Ω/Meter Outside diameter=3mm12K=12000pcs Carbon Fiber Heating Wires=33Ω/Meter Outside diameter=3mm15K=15000pcs Carbon Fiber Heating Wires=28Ω/Meter Outside diameter=3mm18K=18000pcs Carbon Fiber Heating Wires=24Ω/Meter Outside diameter=3mm24K=24000pcs Carbon Fiber Heating Wires=17Ω/Meter Outside diameter=3mm27K=27000pcs Carbon Fiber Heating Wires=15Ω/Meter Outside diameter=3mm36K=36000pcs Carbon Fiber Heating Wires=12Ω/Meter Outside diameter=4mm48K=48000pcs Carbon Fiber Heating Wires=9Ω/Meter Outside diameter=5mm
specification | 힘(여) | Laying area |
2 roots/group | 460 | 3 |
3 roots/group | 690 | 4.5 |
4 roots/group | 920 | 6 |
5roots/group | 1150 | 7.5 |
6 roots/group | 1380 | 9 |
7 roots/group | 1610 | 10.5 |
8 roots/group | 1840 | 12 |
9 roots/group | 2070 | 13.5 |
10 roots/group | 2300 | 15 |
11 roots/group | 2530 | 16.5 |
12 roots/group | 2760 | 18 |
13roots/group | 2990 | 19.5 |
14 roots/group | 3220 | 21 |
포장 & 배달
귀하의 상품의 안전을 더 잘 보장하기 위해, 전문적인, 환경 친화적 인, 편리하고 효율적인 포장 서비스를 제공하겠습니다..
자주하는 질문
1. 우리는 누구인가??우리는 장쑤성에 본사를 두고 있습니다., 중국, 2021 년부터 시작하여 북미로 판매하십시오(90.00%),Domestic Market(10.00%). 총 약이 있습니다 11-50 우리 사무실에 있는 사람들.2. 품질을 어떻게 보장할 수 있나요??대량 생산 전 항상 사전 제작 샘플;항상 배송 전 최종 검사;3.우리한테서 뭘 살 수 있어??Heating Element, 환기 제품, Thermocouple4. 왜 다른 공급업체가 아닌 우리에게서 구매해야 합니까??우리는 제품 품질을 보호하기 위해 업계 자격 인증을 통과했습니다.. We provide one-stop procurement services to reduce the procurement cost for customers.5. 우리는 어떤 서비스를 제공할 수 있나요??허용되는 배송 조건: 본선 인도,EXW,DDP；허용되는 결제 통화:USD;허용되는 결제 유형: 티/티,신용장,D/P D/A;사용 언어:영어,중국인,프랑스 국민
