RV Heater Customized Electric 12V 24v 36v 48v 110v 220v 440v 600v Heating Element for Water Heater RV Heater
Customized Electric 12V 24v 36v 48v 110v 220v 440v 600v Heating Element for Water Heater RV Heater
설명
Customized Electric 12V 24v 36v 48v 110v 220v 440v 600v Heating Element for Water Heater RV Heater
1. The heating elements can be used for both dc(solar PV , battery 12V/24V/36V/48V or custom)and AC electricity(110v/220v/380v or custom), according to customers’ requirements.
2. There are many types of terminals for wiring.
2. There are many types of terminals for wiring.
3.We fill the tube with high purity magnesium oxide powder for longer service life.
4.Custom the Flange size, sheath material, watt,voltage, immersion length, according to applications.
5.Explosion-proof & temperature control features also can be provided, if required.
6. The heating elements are CE,ATEX, CQC,ISO9001,ROHS,UL,CSA certified.Any request, please do not hesitate to let me know.
5.Explosion-proof & temperature control features also can be provided, if required.
6. The heating elements are CE,ATEX, CQC,ISO9001,ROHS,UL,CSA certified.Any request, please do not hesitate to let me know.
제품 특징:
* The size and power all can be designed according to the working environment
* More safer than AC electric
* Environment protection and energy saving.
사양
기술적인 매개변수 | |
튜브 직경 | Φ6.8mm – 20mm |
튜브 길이 | 200mm – 2000mm(맞춤형) |
Thread/tri-clamp/Flange | 1”/1.25”/1.5″ 또는 맞춤형 |
길이 공차 | ±1.5% |
전압 | 12V/24V/36V/48V/110v/220V/380V or Customized |
와트수 | 300W/500W/1kw /1.5kw/3kw or customized |
절연저항 | ≥1000M |
와트 허용 오차 | +5% – 10% |
누설 전류 | 0.5mA 이하 |
저항선 | Ni80Cr20 또는 Cr25AI5 |
외장 재료 | 304 스테인레스 스틸, , 310 스테인레스 스틸, 316 스테인레스 스틸, 인콜로이 800, 인콜로이 840 |
표면 처리 | 세련, 코팅, 도금 |
주문방법 ?Pls는 이 정보를 다음과 같이 제공합니다:(예)1.보타지 :220/380V 2.전력량 :6KW3.길이: 600MM4.스레드: 1 1/2″5. 재료: 스테인레스 스틸, 아이시 321 304, SU 316L
애플리케이션
This product is applicable to Standard American water heater element replacement, 물 예열, 캠핑카, Motor homes, 산업용 기계 및 장비, 자동차 배터리로 어디서나 휴대용 온수 사용 가능, 직접 풍력 및 태양광 응용 분야 및 다양한, many more uses where heat or diversion loads are needed.
제품 세부 정보
회사 프로필
- Taizhou YuLing electrical appliance co.,ltd is a heating element manufacurer in China,장쑤성.
- Yuling is professional in heating industrial more than 40 연령,yuling can provide desinging andproducing heating elements.
- yuling has received ISO system certification and CE CQC UL ROHS product testing certification. Our range of products is primarily sold in the European and American markets.
- We employ stringent quality control measures to ensure the superior quality of our products, and implement impeccable Standard Operating Proceduresto enhance production efficiency, ultimately guaranteeing optimal benefits for our valued customers.
