304 Stainless Steel Single Float Switch Liquid Level Controller Water Level Controller Liquid Level Resistant to Acid and Alkali

$6.77

Secure Closing
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • 페이팔

설명

제품 설명
304 Stainless Steel Single Float Switch Liquid Level Controller Water Level Controller Liquid Level Resistant to Acid and Alkali
그만큼 304 stainless steel single float level controller is an industrial-grade automation component specifically designed for precise monitoring and control of liquid levels. The core material is made of high-quality 304 스테인레스 스틸, which possesses excellent acid and alkali resistance, corrosion resistance, and mechanical strength. It can be widely applied in various complex working conditions for liquid level management, providing stable and reliable water level control solutions for liquid storage, transportation, and processing systems.

Installation precautions for float switches

√ The installation position should be far away from the water inlet; otherwise, the switch may malfunction due to the fluctuation of the water inlet.
√ The load of the controlled circuit must match the contact capacity of the float switch.
√ The specific gravity of the liquid being measured must be greater than that of the float ball.
√ The action point of the float ball has been adjusted at the factory according to the customer’s order requirements. Please do not adjust the position of the float ball at will.
사양
온도
Voltage range
High temperature
0-220V
45mm
High temperature
0-220V
75mm
High temperature
0-220V
100mm
High temperature
0-220V
150mm
High temperature
0-220V
200mm
High temperature
0-220V
250mm
High temperature
0-220V
300mm
High temperature
0-220V
350mm
High temperature
0-220V
400mm
High temperature
0-220V
450mm
High temperature
0-220V
500mm
High temperature
0-220V
600mm
온도
Voltage range
Room temperature
0-110V
45mm
Room temperature
0-110V
75mm
Room temperature
0-110V
100mm
Room temperature
0-110V
150mm
Room temperature
0-110V
200mm
Room temperature
0-110V
250mm
Room temperature
0-110V
300mm
Room temperature
0-110V
350mm
Room temperature
0-110V
400mm
Room temperature
0-110V
450mm
Room temperature
0-110V
500mm
Wiring method
메모:

The single float switch is mainly used for single liquid level alarm. It can be adjusted to either thenormally openornormally closedstate by yourself, and the wiring does not need to be changed.
If you need to control the upper and lower range of the liquid level, two float switches for upper and lower control are required. The wiring diagram can be found in: Double Float Switch.
애플리케이션
This product can be used in water dispensers, purifiers, water heaters, solar energy systems, air conditioners and humidifiers, coffee machines, small refrigerators, 등. Anti-dry-burning water level sensors for water heating equipment are widely used in automobiles, industrial equipment, agricultural equipment, and household appliances.
