Customized Disposable Thermocouple in Kr/Ks/Kb/Kw 602/604 High Temperature Fast Immersion OEM & ODM Support
Descripción
Descripción del Producto
Product Features】 The steel liquid sampler is divided into single chamber and double chamber structures, which have the characteristics ofconvenient use. The sampler is used on site to quickly save time and ensure the quality of steel, in order to reduce waste and improve economic efficiency. Production sampler: used for sampling molten steel that does not require deoxygenation in refining and large ladle after furnace, intermediate ladle; Used for sampling molten steel that needs deoxidation in converters, electric furnaces, open hearth furnaces, etc.. The success rate of sampling is above 98%, the steel sample is full, dense and glossy, and there are no pores. The sampler style can be made according to user requirements. The main features and scope of application are used for rapid extraction of formed steel samples for spectral analysis. It has the characteristics of simple structure and convenient application
【 Instructions for use】
1.Insert the sampler into the dedicated measuring gun;
2.During the measurement,the molten steel sampler is tilted at 60-65 ° and inserted into the molten steel at a depth of over 350MM, with a sampling time of 4-6 seconds; 3.After taking out the sampler from the metal furnace or ladle, gently tap it on the ground, and the steel sample will fall to the ground.【Matters needing attention】1. Samplers must be protected from dampness during storage. 2. Molten steel must be sampled at temperatures above 1400 C. 3. Avoid strong vibration to prevent quartz tube from breaking. 4. Aluminum sampler is used as deoxidizer for steel sample with high oxygen content. Aluminum-free sampler is used asdeoxidizer-free sampler for steel sample with low oxygen content.
Especificación
Nombre | Tipo | specifications | Outer diameter/ thickness of steel sample （mm） | Diameter/length of injection port(milímetros) |
Molten steel sampler | KQNO01G(KQN-01H) | No deoxidizer | Φ34*12 | Φ7*(20-45) |
Molten steel sampler | KQN-002G | No deoxidizer | Φ34*14 | Φ7*(20-30) |
Molten steel sampler | KQN-003G(KQN-031) | No deoxidizer | Φ34*17 | Φ6*(20-30) |
Molten steel sampler | KQN-004G（KQN-04 | No deoxidizer | Φ（32-36）*（65-75） | |
Molten steel sampler | KQY-10IG | Deoxidizer (for low oxygen) | Φ34*12 | Φ7*(20-45) |
Molten steel sampler | KQY-201G | Deoxidizer (high oxygen) | Φ34*12 | Φ7*(20-45) |
Molten steel sampler | KQN-00IT | No deoxidizer | Φ34*12 | Φ10*15 |
Molten steel sampler | KQN-002t | No deoxidizer（rod） | Φ6*50 |
Certificaciones
Embalaje & Entrega
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Preguntas más frecuentes
1. quienes somos?Estamos basados en Jiangsu, Porcelana, start from 2021,sell to North America(90.00%),Domestic Market(10.00%). Hay total sobre 11-50 personas en nuestra oficina.2. ¿Cómo podemos garantizar la calidad??Siempre una muestra de preproducción antes de la producción en masa.;Siempre inspección final antes del envío.;3.¿Qué puedes comprarnos??Elemento calefactor, Ventilation Products, Thermocouple4. ¿Por qué debería comprarnos a nosotros y no a otros proveedores??we have passed the industry qualification certification to protect the product quality. We provide one-stop procurement services to reduce the procurement cost for customers.5. ¿Qué servicios podemos proporcionar??Condiciones de entrega aceptadas: ENGAÑAR,EXW,DDP；Moneda de pago aceptada:Dólar estadounidense;Tipo de pago aceptado: T/T,carta de crédito,D/P D/A;Lenguaje hablado:Inglés,Chino,Francés
