Heater Part 12K 200C Red Low Wattage Carbon Fiber Heating Electric Silicone Part for Floor Heating Pads

Heater Part 12K 200C Red Low Wattage Carbon Fiber Heating Electric Silicone Part for Floor Heating Pads

Kategori:

Beskrivelse

Heater Part 12K 200C Red Low Wattage Carbon Fiber Heating Electric Silicone Part for Floor Heating Pads
Produkt beskrivelse
Carbon Fiber Heating Electric Silicone Part
produktnavn
Carbon fiber heating wire
Leder
Imported carbon fiber wire
Isolering
Silicone/PTFE
Spænding
DC 3-600V / AC 12-380V
Strøm
Voltage*Voltage/(Length*Resistance)
FRA
Silikonegummi: 2-4mm; PTFE: 1.4-3mm
Heating conductor: 1K, 2K, 3K, 6K, 9K, 12K, 18K, 24K,36k,48kInsulating material: Silikonegummi, FluoroplasticWorking voltage: The cable can work on different voltage, but need to use a suitable length, if you don’t know how to calculate the power, please contact us.Key features：* Rapid Heating: Carbon fibers heat up quickly due to their high thermal conductivity.* Even Heat Distribution: The uniform structure of carbon fibers ensures consistent heating across the wire’s length.* Energy Efficiency: Minimal energy loss during heat conversion makes it a cost-effective option.
Carbon Fiber Heating Electric Silicone Part
Carbon Fiber Heating Electric Silicone Part
Carbon Fiber Heating Electric Silicone Part
Usage instructions
1.K represents the meaning of thousands?1K is a thousand silk, 24K is 24 thousand silk (24000) compositionDifferent K numbers represent different resistorsl2.The difference between silica gel and TeflonPTFE/PFA/FEP carbon fiber heating wireAdvantages: Wear, corrosion resistance, no smellDisadvantages: Relative to the silicone are not softSilicone carbon fiber heating wireAdvantages: Resistant to bending, softDisadvantages: There is smell
Carbon Fiber Heating Electric Silicone Part
3.What is the resistance per meter?1K=400Ohm/m, 2K=220Om/m, 3K=133hm/m, 6K=74Ohm/m, 9K=43Ohm/m, 12K=33Ohm/m, 15K=24Om/m, 18K=21Ohm/m, 24K=17Ohm/m, 36K=12Ohm/m,48K=9Ohm/m4. What is the power of the cable? And what is heating temperature?1): 1. The power of the cable is based on the length that you use, you can calculate the power according to above examples.2). Power = 5W/m, the temperature is about 30~40C degrees;Power = 10W/m, the temperature is about 40~50C degrees;Power = 15W/m, the temperature is about 50~60C degrees;Power = 20W/m, the temperature is about 60~70C degrees;Power = 25W/m, the temperatuee is about 70~90C degrees. Please notice that this is for your reference, not exactly right because of different test conditions.5. How to calculated power？Product power calculation:(Voltage*Voltage)÷(resistance*length)=power12K=33ohm/meterFor example, using 10m 12K carbon fiber cable on 220V, the power is:220V*220V÷(10meters*33Ω)=150WFor example, using 15m 12K carbon fiber cable on 220V, the power is:220V*220V÷(15meters*33Ω)=100WThe longer the length, the smaller the power of the heating linePrecautionsThe heating wire can not overlap when used! Can not cross! Cross-over will make the heating line local temperature higher than the melting point of the protective layer, will damage the heating wire!6. About installationThe normal laying power is 100-160 watts per square. Different areas can be increased or decreased according to the room’s own insulation and the type of floor. The installation is very simple, we will guide the installation, the normal laying distance is 12cm.
Ansøgning
Carbon Fiber Heating Electric Silicone Part
Pakning & Levering
Carbon Fiber Heating Electric Silicone Part
Kundevurdering
Carbon Fiber Heating Electric Silicone Part
Carbon Fiber Heating Electric Silicone Part
FAQ
1.Q: Kan vi bruge vores egen speditør?
EN: Selvfølgelig. Vi kan sende det til dem.2. Q: Hvad er betalingsbetingelserne?
EN: Telegrafisk overførsel, 30% depositum før produktion og restbeløbet før levering. Vi kan også acceptere Alibaba Handelsgarantiformular.

3. Q: Hvordan afgiver jeg en ordre?
EN: Send venligst din ordre til os via e-mail, og vi vil bekræfte med dig. Før tilbud, vi vil gerne bekræfte produktinformationen med dig, såsom spænding, watt, størrelse og mængde. Hvis du har detaljerede tegninger, glem ikke at sende dem til os. I hvert fald, kontakt os venligst direkte via e-mail eller online besked.

4. Q: Hvordan garanterer vi kvalitet?
EN: Vi følger strengt produktionsstandarderne for kvalitetsstyring; Tjek værkstedet hver 2 timer; Og har sit eget forsknings- og udviklingsteam og laboratorium.

5. Q: Hvad kan du købe fra os?
EN: Elektriske apparater (dvs. varme varmelegemer, finvarmere, ovnvarmeelementer, cirkulerende varmelegemer) og relaterede produkter;
Hvis der er andre behov, vi kan også hjælpe kunder med at købe.
